Discovery Gooseneck Enclosed Trailer

Sizes Axles Price

DCGN8.5x22TA52 8.5x22-78" Interior-5200# x 2 Call

DCGN8.5x24TA52 8.5x24-78" Interior-5200# x 2

DCGN8.5x26TA52 8.5x26-78" Interior-5200# x 2

DCGN8.5x28TA52 8.5x28-78" Interior-5200# x 2

DCGN8.5x30TA52 8.5x30-78" Interior-5200# x 2

DCGN8.5x32TA52 8.5x32-78" Interior-5200# x 2

DCGN8.5x34TA52 8.5x34-78" Interior-5200# x 2

DCGN8.5x36TA52 8.5x36-78" Interior-5200# x 2

DCGN8.5x38TA60 8.5x38-78" Interior-7000# x 2

DCGN8.5x40TA60 8.5x40-78" Interior-7000# x 2

DCGN8.5x42TTA60 8.5x42-78" Interior-7000# x 3

DCGN8.5x44TTA60 8.5x44-78" Interior-7000# x 3

DCGN8.5x46TTA70 8.5x46-78" Interior-7000# x 3

DCGN8.5x48TTA70 8.5x48-78" Interior-7000# x 3

DCGN8.5x50TTA70 8.5x50-78" Interior-7000# x 3

*Rear Door Opening = 92" W x 79" H

* Overall length included 8’ bunk*

Prices above are factory pick up price in Elkhart, IN.

Standard Features:

• 4"x8" Tube Main Frame (All Sizes)

• Steel Tube Wall Posts (16" O/C)

• Steel Tube Roof Bows (16" O/C)

• Crossmembers (16"O/C)

• Flat Top with Tapered Side Upper Deck

• Cast Aluminum Front Top Corner

• Gooseneck Coupler OR Fifthwheel

• Dual Post 2-Speed Landing Gear

• 5000# Ramp Door w/ Beavertail

• Dexter Torsion Axles w/ E-Z Lube Hubs

• All Wheel Electric Brakes w/Break-Away

• Radial Tires on Silver Modular Steel Wheels

• .030 Aluminum Exterior w/ Screwed Seams

• Brite Front Vertical Corners

• Brite Insert Between Front Corner Castings

• 1 Piece Aluminum Roof

• 3" Top & Bottom Trim w/Cast Rear Corners

• Roof Vent or Flo-Thru Vents

• Framed for Roof Vent

• 3/8" Drymax Interior Walls

• 3/4" Drymax Floor

• 48" Side Door w/Stepwell (Aluminum Framed)

• 24"x36" ATP Baggage Door in Stoneguard

• Zinc Coated Door Hardware

• Aluminum Door Holdback

• Grab Handle on Side Door & Ramp Door

• ATP Exterior Fenders

• 2-12V LED Interior Lights w/ 1 Switch

• LED Strip Tail & Clearance Lights (7/Side)

• LED Mid-Ship Turn Signals

• 6" Barrier Tape

• DOT / C.S.A. Approved Safety Equipment

• 7 Way Electrical Plug

• 3 Year Structural Warranty

• 1 Year Limited Warranty

Listed below are some popular options available for the Spread Axle Model:

Larger axles available, please call for pricing.

40” Tandem Spread Axle $500.

40” Triple Spread Axle $850.

50" Super Spread Axle $575. (tandem)

Single ram hydraulic jack with battery $1,675

Bull Nose Front Model (Flat front): Cast Corners, polished top wrap & ATP corners. $500.

54"T x 54"H Drive side escape door with strap hinges & barlock $495.

60”T x 84’W Flip Up Driver side escape door with gas shocks and interior latch $740.

Premium Driver Escape Door: 40” Spread Axle 90”W x72”H : Top hinge W gas struts, removable wheel box, frame mounted step, keyed aluminum compression latches $2,850.

Premium Driver Escape Door: 50” Spread Axle 100”W x72”H : Top hinge W gas struts, removable wheel box, frame mounted step, keyed aluminum compression latches $3,350.

36" RV Door w/ Window & Screen $625.

48" RV Door w/ Window & Screen $725.

Double Side RV Door w/ Flushlock- 48" x 78" $865.

Double Side RV Door w/ Flushlock- 60" x 78" $985.

Extra trailer height, Call for pricing.

Two Tone Colors with brite stripe $250.

.040 Exterior aluminum skin, call for pricing

.050 Exterior aluminum skin, call for pricing

.080 Aluminum-tec skin, call for pricing

Recessed latch $75.

Recessed HD latch for ramp door (stainless steel only) $450.

One piece piano hinges for side door $100.

Recessed floor E-track $15. per ft.

Recessed wall E-track $15. per ft.

E-track clips (light duty), each $25.

Recessed D-ring each $25.

Corner post drop down jacks (pair) $125.

Skid rollers welded under rear (pair) $175.

Set of 15” Aluminum Wheels $525.

Set of 16” Aluminum wheels $650.

205/75R/15 Spare tire on steel wheel $160.

225/75R/15 Spare tire on steel wheel $200.

235/80R/16 Spare tire on steel wheel $250.

Interior spare tire mount $85.

In floor spare tire compartment $325.

White vinyl insulated ceiling: 1” Owens Corning pick board R-5. Call for pricing.

.030 Aluminum walls over 3/8” Drymax walls. Call for pricing.

9mm White Vinyl in place of 3/8” Drymax walls on sidewalls. Call for pricing.

.030 Aluminum ceiling. Call for pricing.

Insulated walls - 1” Owens Corning pink board R-5. Call for pricing.

Black Rubber Coin floor for trailer main floor $37. Per trailer foot.

Black Rubber Coin floor on ramp door & flap $250.

ATP Floor Installed Over Standard Wood on Floor $50. Per trailer foot.

ATP on Ramp Door & Flap $475.

ATP on step well only $140.

Roof Vent $50.

Max Air Vent Cover $100.

9.5" x 4" Aluminum Direction Sidewall vents (pair) $100.

Aluminum Flat Top roof ladder racks (each) $150.

13,500 BTU AC $1,125.

Heat Strip for AC $125.

110 Electrical Package: (2) 48” 110 volt LED lights, (1) light switch (3) 110-volt interior receptacles, (1) 30 amp service panel with 25' lifeline and cable hatch, $600.

Additional 4' 110 volt L.E.D. Light $110.

8' Straight Overhead Cabinet $575.

8' Straight Base Cabinet w/aluminum counter top $775.

L-Base Cabinet with aluminum counter top $895.

36”W x24”H Generator door without box $250.

Insulated generator compartment (24” deep) $525.

LED Mid-Ship Turn Signals (1 PR) $100.

Additional LED clearance light each $15.

Additional 12v LED Dome Light each $25.

Pair of 6” Strip L.E.D. Back Up Lights $150.

2nd set of LED Strip taillights $100.

2-12 Volt LED rear loading lights with switch $150.

Rear Spoiler/Wing NO load lights $495.

Rear Spoiler/Wing WITH LED load lights & switch $625.

Winch package: 4,000 lb. Winch w/remote, battery & box $1,400.

Winch plate only $80.

3' Aluminum flap for ramp door with 3" bumpers (great for low clearance vehicles) $1,120.

5’ Aluminum flap for ramp door with 3” bumpers (great for low clearance vehicles) $1,560.

15”x30” Horizontal Slider Window with screen $200.

30”x15” Vertical Slide Window with screen $200.

30”x30” Horizontal Slider Window with screen $250.

8’x 8’ Roof Platform with folding rails & ladder $1,450.

Awnings, call for pricing.

TSC Interior Car Hauler Package: Call for pricing.

9mm White Vinyl Walls I.P.O. 3/8" DrymaxWhite Vinyl Ceiling Liner w/ Colored Coves (Non-Insulated)Black Coin Rubber Floor & Ramp Door(3) 48" LED Fluorescent Lights(4 Lights 22' & Above trailer)(3) Interior Recepts (Non GFI)(1) 110v Switch(2) LED Rear loading Lights with switch30a Panel w/ Motorbase Plug & 25' Twistlock Cord

BLACK OUT Package: Thermo-Coat process. 10x more durable than powder coating. Black Exterior Trim, Black Stone Guard, Black Fenders, Black Door Hardware, Black Steel Modular Wheels. Main frame not included. $43.00 Per trailer foot.

Stereo Package: Boss Stereo w/ AM/FM/CD/BT-Touch Screen (4) Weather Proof Speakers (2 Interior, 2 Exterior), Antenna, $650. (must add 12 volt battery)

Deluxe Stereo Package: Kenwood Stereo w/ AM/FM/CD/BT (4) Interior Speakers (2) Exterior Speakers (1) Sub-Woofer (1) Amplifier, Antenna, $1,825. (must add 12 volt battery)

12 volt Battery With Box & Wiring $300.

Bathroom Package A: (Requires 84" Minimum Interior Height for Shower) Low Profile Toilet, 32" x 32" x 6" Shower, Shower Assembly, 15" x 15" Stainless Steel Sink, Faucet, Cabinet, 110 V Water Pump, 6 Gallon Water Heater - 110v Electric, Black/Grey/ Fresh Water Tanks, City Water Fill, Vent, Partition Walls w/Door, Medicine Cabinet, 12v Dome Light w/Switch, All Plumbing Accessories Required. $5,100.

Bathroom Package B: Low Profile Toilet, 15" x 15" Stainless Steel Sink, Faucet, Cabinet, 110V Water pump, 6 Gallon Water Heater - 110v Electric, Black/ Fresh Water Tanks, City Water Fill, Partition Walls w/Door, 12v Dome Light w/Switch, All Plumbing Accessories Required. $4,100.

We offer many more options not listed, call for availability and pricing.

Check out our Photo Gallery page for built examples of this trailer.

Financing is available:

To order a trailer or have any questions, call 270 535 4860

Prices may also be changed without notice due to unforeseen cost increases of imported products, raw materials, or economic instability. We are not responsible for customer pricing errors.
